Specifiche
CategoriaMountain
SottocategoriaEnduro
Anno2023
TelaioFoxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspe...
Materiale del telaioAluminum
ForcellaFox 36 29 Float GRIP EVOL Rhythm, 160mm, tapered steerer tube,...
Peso15.6 kg
SospensioneFull
Ammortizzatore posterioreFox Float DPS LV EVOL Performance, 205x62.5mm. Settings: rebou...
EscursioneNULL
Taglie
XXXXXXXX
Componenti
Gruppo
SX Eagle
Trasmissione
1 X 12
Deragliatore posteriore
SRAM SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Catena
SRAM SX Eagle, 12s, Powerlock
Guarnitura
SRAM SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm, Rings: 32T, steel, X-Sync 2
Movimento centrale
SRAM DUB BSA, sealed bearings, 73mm
Tipo di freno
Hydraulic Disc
Freni
SRAM G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Leve freno
SRAM G2 R, tool-free reach adjust
Manubrio
ONOFF Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Attacco manubrio
ONOFF Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Manopole
ONOFF Twin, 1lock-on, 135mm
Sella
SDG BEL-AIR 3.0, LPU foam, steel rails
Reggisella
ONOFF Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
Ruote e pneumatici
Dimensione ruota
29
Materiale della ruota
Aluminum
Cerchi
e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes
Raggi
e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers
Pneumatici
Front: Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead, Rear: Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Larghezza pneumatico
2.5"
