Componenti
Gruppo
105 Di2
Trasmissione
2 × 12 Electronic
Deragliatore anteriore
Shimano 105 R7150 Di2, braze-on, down swing
Deragliatore posteriore
Shimano R7150 Di2, 36T max cog
Cassetta
Shimano 105 7101, 11-34, 12 speed
Catena
Shimano SLX M7100, 12-speed
Guarnitura
Size: 44, 47, Shimano 105 R7100, 50/34, 165mm length; Size: 50, 52, Shimano 105 R7100, 50/34, 170mm length; Size: 54, 56, Shimano 105 R7100, 50/34, 172.5mm length; Size: 58, 60, 62, Shimano 105 R7100, 50/34, 175mm length
Movimento centrale
Praxis, T47 threaded, internal bearing
Tipo di freno
Hydraulic Disc
Freni
Shimano RT70, centerlock, 160mm
Manubrio
Size: 44, 47, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 36cm width; Size: 50, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width; Size: 52, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width; Size: 54, 56, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm width; Size: 58, 60, 62, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width
Attacco manubrio
Size: 44, Trek RCS Pro, -7 degree, 60mm length; Size: 47, Trek RCS Pro, -7 degree, 70mm length; Size: 50, Trek RCS Pro, -7 degree, 80mm length; Size: 52, 54, Trek RCS Pro, -7 degree, 90mm length; Size: 56, 58, Trek RCS Pro, -7 degree, 100mm length; Size: 60, 62, Trek RCS Pro, -7 degree, 110mm length
Sella
Size: 44, 47, 50, 52, Verse Short Comp, steel rails, 155mm width; Size: 54, 56, 58, 60, 62, Verse Short Comp, steel rails, 145mm width
Reggisella
Size: 44, 47, 50, 52, 54, 56, KVF aero carbon seatpost, 20mm offset, 280mm length; Size: 58, 60, 62, KVF aero carbon seatpost, 20mm offset, 320mm length
