Specifiche
CategoriaMountain
SottocategoriaTrail
Anno2024
TelaioE-Bravo HPR, 3BS 6061 Hydroformed and aluminum parts with Tech...
Materiale del telaioAluminum
ForcellaRockShox 35 GOLD RL, Motion Control, 15x110mm Maxle Stealth, T...
SospensioneHardtail
Componenti
Gruppo
NX Eagle
Trasmissione
1 X 12
Deragliatore posteriore
SRAM NX Eagle, Aluminum cage, 12 Speed
Cassetta
SRAM PG 1210 Eagle, 11-50T
Catena
SRAM SX Eagle A1, 118 links
Guarnitura
Bafang Aluminum Alloy Cranks, 165-170mm, 34T
Movimento centrale
BSA, 73mm, threaded
Tipo di freno
Hydraulic Disc
Freni
SRAM DB8 Black 4 Piston
Manubrio
Avanforce AF2 MTB, Aluminum 6061, Ø31,8mm, width 780mm, Backsweep 6°, Upsweep 5°, Rise 20mm, weight: 330gr
Sella
Essax Era, Steel rails, length: 250mm, width: 145mm, weight: 280gr
Reggisella
Avanforce AF2, Aluminum 7075, 0 offset, Ø31,6 x 400mm, weight 205gr
Ruote e pneumatici
Dimensione ruota
29
Cerchi
Mavic E-Crossride 29", 15x110, Boost 12x148mm, TLR, HG11 Rear Hub, 6 Bolts, internal width: 30mm, weight: 2225gr
Pneumatici
Vittoria Barzo 29x2,35", Tubeless ready, Graphene 2.0, 120 TPI, weight: 820gr
E-Bike
Motore
Bafang 250W 60Nm mid-drive
Descrizione del motore
BAFANG M-SERIES 510, 250W - 60Nm, Peak Power and Torque: 500W - 95 Nm, Q factor 177mm, weight: 3370gr
Coppia motore
60 Nm
Batteria
720Wh
Descrizione della batteria
PORTAPOWER 720Wh 36V 20Ah, Cells SAMSUNG INR21700-50E, 3960g
Capacità della batteria
720 Wh
