Specifications
CategoryUrban
SubcategoryCargo/Long-Tail
Year2022
Frame6061 aluminum
Frame materialAluminum
ForkRST spring fork, 80 mm travel, with lockout and preload adjust...
Weight34.9 kg
SuspensionHardtail
TravelNULL
Colors
XXXXXXXX
Sizes
XXXXXXXX
Components
Groupset
Tourney, Acera
Drivetrain
1 X 7
Rear derailleur
7-speed Shimano Acera
Cassette
7-speed freewheel, 11-34T
Chain
KMC Z7
Crank
48T, 170 mm forged alloy, dual-sided aluminum bashguard
Bottom bracket
100 mm Square Taper Bottom Bracket
Brake type
Mechanical Disc
Brakes
Tektro Aries ,MD-M300)
Brake levers
Aluminum alloy comfort grip levers with motor cutoff switch and integrated bell
Handlebar
Aluminum high rise, 686 mm wide, 10" rise
Stem
50 mm + 30º (15 mm rise)
Grips
Durable imitation leather ergonomic grips
Saddle
Custom Rad Power Bikes moped-style, integrated steel seat post, fixed angle
Seatpost
390 mm x 27.2 mm
Pedals
Wellgo B087 CrMo axle, forged aluminum platform with reflectors, standard 9/16" x 20 TPI threading
Wheels & Tires
Wheel size
20
Wheel material
Aluminum
Rims
Double wall aluminum, 36 hole, Rim width: 55 mm
Spokes
12-gauge stainless steel, black
Tires
Exclusive Rad Power Bikes by Kenda K-Rad 20" x 3.3", K-Shield puncture-resistant liner *tires received may not include branding
Tire width
3.3"
Tire clearance
4"
E-Bike
Motor
750W 80Nm hub-drive
Motor description
750W brushless Rad Power Bikes geared hub motor with 80 Nm of torque, 5:1 planetary gear reduction. Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions.
Motor torque
80 Nm
Battery
672Wh
Battery description
672 Wh
Battery capacity
672 Wh
