Composants
Transmission
1 X 10
Dérailleur arrière
Shimano CUES RD-U6000, Shadow RD Plus for optimal chain guidance, smooth and reliable shifting performance, rear derailleur stabilizer to prevent chain impact, also optimized for e-bikes, especially for LINKGLIDE, largest pinion max. 50 teeth
Cassette
Shimano CS-LG400-10, 10-speed LINKGLIDE, gradation: 11-13-15-17-20-23-26-30-36-43, increased wear resistance
Chaîne
Shimano CN-HG601, HG-X 11-speed, optimized shifting behavior, dirt-repellent design, SIL-TEC coating for longer durability
Pédalier
FSA CK-762, crank length: 170 mm, material: forged 6061/T6 aluminum, finish: black anodized, Q-factor: 177 mm
Boîtier de pédalier
Bosch, press-fit
Type de frein
Shimano Mt201, Hydraulic Disc Brake, Reliable Entry-Level Brake, Comfortable Even For Smaller Hands, Comfortable 3-Finger Brake Lever, Brake Calliper: Br-Ur300 2-Piston, Brake Pad: B05S-Rx Resin
Cintre
TRENGA, width: 640 mm, handlebar clamp Ø: 31.8 mm, backsweep: 9°
Potence
FSA NS SMR integrated, length: depending on frame size, fork tube clamp Ø: 28.6 mm, handlebar clamp Ø: 31.8 mm, angle: - 6°, internally routed shift cables and brake lines
Selle
Selle Italia ST-5 Flow, combines comfort with sporty design, FLOW opening relieves the perineal area, gel padding with Soft-Tek cover, Hi-Viz inserts increase visibility in the dark
Tige de selle
TRENGA aluminium rigid, diameter: 31.6 mm, length: depending on frame size: 300/400 mm, clamping: 2-fold, offset: 10 mm
Pédales
TRENGA HPL Platform, non-slip tread for more safety, aluminum pedal body, reflectors
Roues & Pneus
Taille des roues
700
Jantes
Ryde Zac 25, versatile and durable all-round rim, 32 holes, tubeless ready, ETRTO: 25-622
Rayons
Sapim Race, Material: Stainless steel, Diameter: 2.0 / 1.8 mm, Color: Black
Pneus
Schwalbe Marathon Race, ETRTO: 40-622, Light and sporty, SpeedGrip compound for best driving characteristics, Good puncture protection through RaceGuard, Reflective strips, For special e-bike requirements
