Componentes
Grupo
Ultegra Di2
Transmisión
2 X 12
Desviador delantero
Shimano Ultegra R8150 Di2, braze-on, down swing
Desviador trasero
Shimano Ultegra R8150 Di2, 34T max cog
Cassette
Shimano Ultegra R8100, 11-34, 12 speed
Cadena
Shimano Ultegra/XT M8100, 12 speed
Bielas
Size: 47, Shimano Ultegra R8100, 50/34, 165mm length; Size: 50, 52, Shimano Ultegra R8100, 50/34, 170mm length; Size: 54, 56, Shimano Ultegra R8100, 50/34, 172.5mm length; Size: 58, 60, 62, Shimano Ultegra R8100, 50/34, 175mm length
Pedalier
Praxis, T47 threaded, internal bearing
Tipo de freno
Shimano Ultegra Hydraulic Disc, Flat Mount
Frenos
Shimano CL800, centerlock, 160mm
Manillar
Size: 47, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 36cm width; Size: 50, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width; Size: 52, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width; Size: 54, 56, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm width; Size: 58, 60, 62, Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width
Potencia
Size: 47, Trek RCS Pro, -7 degree, 70mm length; Size: 50, Trek RCS Pro, -7 degree, 80mm length; Size: 52, 54, Trek RCS Pro, -7 degree, 90mm length; Size: 56, 58, Trek RCS Pro, -7 degree, 100mm length; Size: 60, 62, Trek RCS Pro, -7 degree, 110mm length
Sillín
Size: 47, 50, 52, Bontrager Verse Short Comp, steel rails, 155mm width; Size: 54, 56, 58, 60, 62, Bontrager Verse Short Comp, steel rails, 145mm width
Tija
Size: 47, 50, 52, 54, 56, KVF aero carbon seatpost, 20mm offset, 280mm length; Size: 58, 60, 62, KVF aero carbon seatpost, 20mm offset, 320mm length
Ruedas y neumáticos
Tamaño de rueda
700
Material de la rueda
Carbon
Llantas
Front: Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle, Rear: Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, Shimano 11 speed freehub, 142x12mm thru axle
Neumáticos
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm
Ancho del neumático
32c
Holgura del neumático
38c
